160 kVA / 128 kW 3 Phase Battery Backup Uninterruptible Power Supply (UPS) And Power Conditioner

The 160,000 VA (160 kVA) / 128,000 Watt (128 kW) online pure sine wave battery backup uninterruptible power supply (UPS) and power conditioner with surge protection automatically provides defense against power problemsGive your electronics longer life while protecting them from harmful dirty power problems that may otherwise damage or degrade their performance. Much more than a battery in a box, every Battery Backup Power, Inc. system doubles as a power conditioner, actively correcting voltage issues left unresolved by the power company or created by other power hungry electronics in your home or office (laser printers, HVAC systems, refrigeration equipment, etc.).

Do you need a PDF quote or a custom emergency backup solution? Email us at engineering@batterybackuppower.com

Financing Available Through U.S. Business Funding. Download And Submit A Credit Application To Receive Financing Options.

  • Model Number: BBP-33-160K
  • 160,000 VA (160 kVA) / 128,000 Watt (128 kW)
  • 3 Phase
  • Tower
  • Pure Sine Wave Clean Output To Operate And Maximize The Life Of Even The Most Sensitive Electronics
  • Online (Double Conversion) - Highest Level Of Protection Available - Battery Power Always Engaged, No Switching Delay
  • Accepts Generator Power (Direct or On Automatic Transfer Switch)
  • Constant Voltage Regulation
  • Constant Frequency Regulation
  • Factory Warranty: 3 Years On Electronics And 1 Year Warranty On Batteries
  • Optional Extended Warranty: 6 Years On Electronics And 3 Year Warranty On Batteries
  • Heavy Duty Industrial Grade For Constant Use
  • For Use With Laboratory Instruments
  • For Use With Medical Devices
  • For Use With Hospital Equipment
  • For Use With Sensitive IT Equipment
  • 0.8 Power Factor
  • 12-Pulse Rectifier
  • Output Circuit Breaker
  • Battery DC Breaker
  • UL Required Anti-Backfeed Input Contactor
  • Local EPO Pushbutton Station
  • Remote EPO Interface Connection
  • UL Listed Wire and Cable
  • UPSCOM Software CD
  • 6 Foot Long RS232 Communication Interface Cable
  • Battery Options:
    • 58 Batteries, 12 Volt, 88 Amp Hours Each
    • Contact Us For Custom/Non-Listed Battery Configuration
  • Input Options:
    • 190V / 208V / 220V / 240V / 380V / 400V / 415V / 440V / 460V / 480V / 600V / CUSTOM
    • 3 Phase 3 Wire, 3 Phase 4 Wire, Or 3 Phase 5 Wire
  • Output Options:
    • 190V / 208V / 220V / 240V / 380V / 400V / 415V / 440V / 460V / 480V / 600V / CUSTOM
    • 3 Phase 3 Wire, 3 Phase 4 Wire, Or 3 Phase 5 Wire
  • Full Load Estimated Run Time On Battery Power:
    • 10 Minutes With Internal Batteries
    • Contact Us For Additional Battery Cabinet Configurations
  • Built To Order: Takes 12-16 Weeks For Delivery
  • Operating Temperature Rating: 0C ~ +40C
  • Humidity: 10% ~ 90% R.H. (Non-Condensing)
  • Add A Power Failure Cellular Text/SMS Alert Module
  • Free Shipping/Freight Within The United States Or To U.S. Based Freight Forwarder Specified Location (List U.S. Based Location Specified By Forwarder In Shipping Address For International Orders)

User Guide:
BBP 10K-400K 3 Phase UPS User And Installation Guide

Spec Sheet/Cut Sheet:
BBP 10K-400K 3 Phase UPS Model Specifications

Get an estimation of how long your electronics will run on backup battery power with this unit during a power outage. Write down the Power Factor, Number of Batteries, Voltage of Batteries, and Amp Hour Rating from above, then click here to go to our uninterruptible power supply (UPS) backup run time calculator
